| General moped information |
|---|
| Model: | Yamaha Aerox R 50 |
| Year: | 2013 |
| Category: | Scooter |
| Rating: | 3.6 View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike. |
| Engine and transmission |
|---|
| Displacement: | 49.2 ccm (3.00 cubic inches) |
| Engine type: | Single cylinder, two-stroke |
| Power: | 3.3 HP (2.4 kW)) @ 6750 RPM |
| Torque: | 3.5 Nm (0.4 kgf-m or 2.6 ft.lbs) @ 6500 RPM |
| Compression: | 12.0:1 |
| Bore x stroke: | 40.0 x 39.2 mm (1.6 x 1.5 inches) |
| Fuel system: | Carburettor. Gurtner |
| Ignition: | CDI |
| Lubrication system: | Separate lubrication |
| Cooling system: | Liquid |
| Gearbox: | Automatic |
Transmission type,
final drive: | Belt |
| Driveline: | V-Belt Automatic |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Steel |
| Front suspension: | Telescopic fork |
| Front wheel travel: | 80 mm (3.1 inches) |
| Rear suspension: | Unit swing |
| Rear wheel travel: | 60 mm (2.4 inches) |
| Front tire: | 130/60-13 |
| Rear tire: | 140/60-13 |
| Front brakes: | Single disc |
| Diameter: | 190 mm (7.5 inches) |
| Rear brakes: | Single disc |
| Diameter: | 190 mm (7.5 inches) |
| Wheels: | Black, five spoke |
| Physical measures and capacities |
|---|
| Weight incl. oil, gas, etc: | 97.0 kg (213.8 pounds) |
| Seat height: | 828 mm (32.6 inches) If adjustable, lowest setting. |
| Overall length: | 1743 mm (68.6 inches) |
| Overall width: | 690 mm (27.2 inches) |
| Ground clearance: | 185 mm (7.3 inches) |
| Wheelbase: | 1256 mm (49.4 inches) |
| Fuel capacity: | 7.00 litres (1.85 gallons) |
| Other specifications |
|---|
| Color options: | Red/white, Blue/black, Tech armor/black |
| Starter: | Electric & kick |
| Instruments: | High-spec LCD instruments |
| Carrying capacity: | Under-seat helmet storage for a full-face helmet. |
| Modifications compared to previous model: | New dual seat with sports riding position. |
